5" Submersible Pumps DSP5RF

20%

5″ Submersible Pumps DSP5RF

$20.00

5″ Submersible Pumps DSP5RF
Cast Iron

Product Description

Description

Duke’s DSP5RF – Series pumps are 5″ Borewell Submersible pumps suitable for clear water, high head applications. The casing & Impellers are made up of either casted Iron / Stainless Steel or the combination. These Pumps are of Multistage Centrifugal types, accommodating Radial flow Impellers according to the required Head & Flow. The Pump & Motor are joined with Keyway coupling for easy serviceability. The precise design, materials combination, manufacturing process and stringent quality assurance procedures ensure high quality performance and durability of the pumps. These Pumps are coupled with Rigid, High-efficient, Water-filled, Rewindable submersible motors.

Technical Specification

Technical Specification

Nominal Diameter 5″ (RADIAL)
Power Range 2.0 – 15.0HP
Nominal Speed 2820 RPM
MAX Flow 23.4 m3/h
Shut-off Head 405 m
Outlet sizes 2″
Shaft Coupling Key way

Features

Features

  • Optimal Design
  • Precisely made parts
  • High Operating Efficiency
  • Hygiene
  • Good resistance to salt

Applications

Applications

  • Irrigation
  • Industrial
  • General Water Supply
  • Pressure boosting units
  • Fountains
  • Gardens
  • Sprinkler systems
