4" Submersible Pumps DSP4RFF

4″ Submersible Pumps DSP4RFF

$11.05

4″ Submersible Pumps DSP4RFF
Stainless Steel (Fabricated)

Product Description

Description

Duke’s DSP4RFF – Series pumps are fully Stainless Steel, Fabricated, 4″ Borewell Submersible pumps suitable for clear water, high head applications. These Pumps are of Multistage Centrifugal types, accommodating Radial flow Impellers according to the required Head & Flow. The Pump & Motor are joined with Keyway coupling. The precise design, materials combination, manufacturing process and stringent quality assurance procedures ensure high quality performance and durability of the pumps. These pumps are available in SS 304 & SS 316 constructions.

Technical Specification

Technical Specification

Nominal Diameter 4″ (100 mm)
Power Range 0.5 – 7.5 HP
Nominal Speed 2900 rpm
Flow Range 1 – 18.0 m3/h
Shut-off Head 510 m
Outlet sizes 1.5″, 2″
Shaft Coupling Keyway / Splines
Max. Operating Pressure 50 bar

Features

Features

  • Optimal Design
  • Precisely made parts
  • High Operating efficiency
  • Good resistance to salt
  • Hygiene
  • Durable

Applications

Applications

  • Residential
  • Irrigation
  • Pressure boosting units
  • Fountains
  • Gardens
  • Sprinkler systems
  • Food processing industry
