6″ SUBMERSIBLE MOTORS DSM6 IE3
WATER FILLED
Product Description
Description
Duke’s DSM6 – Series motors are Re-windable, wet type, water cooled, Submersible motors, designed to drive Duke’s submersible pumps. They are available upto 37 kW as standard supply. The windings are made up of EC grade copper conductor and Polywrap insulation of excellent resistivity and water-proof property . High performance, specially designed, water lubricated thrust bearings are provided to withstand high axial thrust loads exerted by whole borewell water column and pumping systems. These motors are available in different types of MoCs like Fully Stainless Steel or Cast Iron constructions. The are available in Keyway coupling.
Technical Specification
Technical Specification
Nominal Diameter | 6″ Motor (150 mm) |
Max. Outer Diameter | 144 mm |
Power Range | 1 Ph – 3 – 10 HP 3 Ph – 3 – 40 HP |
Nominal Speed | 2900 rpm |
Voltage Range | 1 Phase 230 V, 50 Hz, A.C Supply 3 Phase 380-415 V, 50 Hz, A.C Supply |
Class of Insulation | F |
Degree of Protection | IP 58 |
Direction of rotation | Anti-Clock wise |
Shaft Coupling | Keyway / Splines |
Type of duty | S1 (Continues) |
Max. Liquid temp. | 33° C |
Starts per hour | 20 Times |
Method of starting | 1 Phase – Capacitor Start Capacitor Run 3 Phase – Direct On Line (DOL) / Star-Delta(SD) |
Features
Features
- Rewindable
- Durable Optimal design
- Heavy thrust bearings
- Easy to dismantle & repair
- High Operating Efficiency
- Different types of MoCs
Applications
Applications
- Irrigation
- Industrial
- General Water Supply
- Farms
- Pressure Boosting Systems
