Duke’s DSP6MFHSS – Series pumps are casted Stainless Steel, Borehole/ Deep well Submersible pumps suitable for clear water, high head applications.
Duke’s DSP6MFHSS – Series pumps are casted Stainless Steel, Borehole/ Deep well Submersible pumps suitable for clear water, high head applications. These Pumps are of Multistage Centrifugal types, accommodating Mixed flow impellers according to the required Head & Flow. The casted construction makes the pump long lasting against sand particles in water. The mounting dimensions are according to NEMA Standard which enables the pumps to be coupled with any NEMA standard submersible motors. The precise design, materials combination, manufacturing process and stringent quality assurance procedures ensure high quality performance and durability of the pumps. These pumps are available in SS 304 & SS 316 constructions and key way shaft can also be supplied against requirements
| Nominal Diameter | inch / mm | 6”(150mm) |
| Power Range | kW / HP |
2.2 – 22 kW 3 – 30 HP |
| Nominal Speed | rpm | 2900 rpm |
| Flow Range | m3/h | 6.6 – 75 m3/h |
| Shut-off Head | m | 350 |
| Outlet sizes | inch | 3″ |
| Shaft Coupling | – | Splines/Keyway |
| Mounting Standard | – | NEMA / Int’l Std |
| Max. Operating Pressure | bar | 35 bar |
Residential
Industrial
Irrigation
Fountains
Gardening
Solar
| Power Range | 26 - 78 kW |
| Discharge | Upto 498 m3 /h |
| Head | Upto 90 m |
| Power Range | 1Ph: 2.2 - 7.5 kW 3Ph: 2.2 - 45 kW |
| Nominal Speed | 2900 rpm |
| Power Range | 0.55 - 1.1 kW |
| Discharge | Upto 4 m3 /h |
| Head | 113 m |
| Power Range | 5.5 - 75 kW |
| Discharge | 48 - 120.0 m3 /h |
| Head | 400 m |
