Duke’s DSP-Series pumps are Casted Iron, Borehole / Deep well Submersible pumps suitable for clear water, high head applications. The casing & Impellers are made up of either casted Iron / Stainless Steel or the combination.
Duke’s DSP-Series pumps are Casted Iron, Borehole / Deep well Submersible pumps suitable for clear water, high head applications. The casing & Impellers are made up of either casted Iron / Stainless Steel or the combination. These Pumps are of Multistage Centrifugal types, accommodating Mixed flow impellers according to the required Head & Flow. The mounting dimensions are according to NEMA Standard which enables the pumps to be coupled with any NEMA standard submersible motors. Key-way models are also availble. The precise design, materials combination, manufacturing process and stringent quality assurance procedures ensure high quality performance and durability of the pumps.
| Power Range | kW / HP |
27 – 78 kW 35 – 105 HP |
| Nominal Speed | rpm | 2900 rpm |
| Flow Range | m3/h | 132 – 498 m3/h |
| Shut-off Head | m | 90 m |
| Outlet sizes | inch | 8″ |
| Shaft Coupling | – | Splines |
| Mounting Standard | – | NEMA |
| Max. Operating Pressure | bar | |
| Min. Cooling Flow | m/s | 0.2 m/s |
Residential
Industrial
Irrigation
Fountains
Gardening
Solar
| Power Range | 5.5 - 75 kW |
| Discharge | 48 - 120.0 m3 /h |
| Head | 400 m |
| Power Range | 5.5 - 75 kW |
| Discharge | 48 - 120.0 m3 /h |
| Head | 400 m |
| Power Range | 0.55 - 63 kW |
| Discharge | 6 - 72.0 m3/h |
| Head | 650 m |
